8.4″ monochrome TFT monitor for Cybelec CNC 3200 controllers 9″monochrome CRT

  • 8.4″ monochrome TFT monitor for  Cybelec CNC 3200 controllers 9″monochrome CRT
  • 8.4″ monochrome TFT monitor for  Cybelec CNC 3200 controllers 9″monochrome CRT
  • 8.4″ monochrome TFT monitor for  Cybelec CNC 3200 controllers 9″monochrome CRT
  • 8.4″ monochrome TFT monitor for  Cybelec CNC 3200 controllers 9″monochrome CRT
  • 8.4″ monochrome TFT monitor for  Cybelec CNC 3200 controllers 9″monochrome CRT
  • 8.4″ monochrome TFT monitor for  Cybelec CNC 3200 controllers 9″monochrome CRT
  • 8.4″ monochrome TFT monitor for  Cybelec CNC 3200 controllers 9″monochrome CRT
  • 8.4″ monochrome TFT monitor for  Cybelec CNC 3200 controllers 9″monochrome CRT
  • 8.4″ monochrome TFT monitor for  Cybelec CNC 3200 controllers 9″monochrome CRT
  • 8.4″ monochrome TFT monitor for  Cybelec CNC 3200 controllers 9″monochrome CRT
Model No.︰HCM1011084OCYB
Brand Name︰HarmonyWolrd
Country of Origin︰China
Unit Price︰US $ 520 / pc
Minimum Order︰1 pc
Share on:

 Total 797 Related Items
Prev656657658659660Next

Product Description

This Cybelec CNC 3200 monitor is a modern 8.4″ monochrome (green) TFT LCD replacement display for the original 9″ monochrome CRT monitor that was fitted to the Cybelec CNC 3200 controllers.

It is pre-programmed with the special Cybelec timing so that it automatically detects and syncs the video on power up.

As seen in the images, it mounts directly into the Cybelec chassis without the need for modifications.

Connection to the monitor is via the 10 pin monitor connector “ADA-CRT10”, which supplies the video signal and the 12V DC power to the monitor.

Original monitor: Cybelec CNC 3200 9″monochrome CRT
Replacement monitor: 8.4″ monochrome (green) TFT LCD
Controller: Cybelec CNC 3200

About Our Cybelec CNC 3200 Monitor

Our Cybelec replacement monitor is designed and built by HMWTECH CO.,ltd. The level of engineering and attention to detail in this German made product is second to none. It has been specially developed to give the same operation as the original Cybelec CNC 3200 CRT monitor, but with higher performance and greater reliability. The display is crisper and brighter, making it much easier to read, and the fully integrated power supply uses modern technology that lowers your running costs. It is mechanically and electrically compatible with the original Cybelec monitor, and is supplied with all the relevant cables and connectors to ensure a fast, plug and play installation.

Specification:

  • 8,4″ TFT LED industrial monitor as a replacement to 9″ tube monitors at Cybelec CNC 3200 control units
  • Mechanics: Chassis
  • Connection: 10 pin adapter cable ADA CRT10
  • Voltage: 12V DC via adapter cable
  • Display resolution: 800 x 600 pixel
  • Brightness: 250 cd/m2
  • Contrast ratio: 600:1
  • Backlight: approx. 20.000 operating hours
  • designed for 24/7 continuous operation
  • 2 year warranty
  •
